Wherever your adventures take you, enjoy the creature comforts of warm water, for washing up or a quick wash down.

Pundmann campervan water heaters provide hot water on the go. The options for power are flexible and are offered in a range of combinations , including a hot air heat exchanger from an additional  diesel heater, and 12v or 230v heating elements.

We offer the choice of size and style to suit your space, needs and budget.

The Pundmann campervan water heater is designed for off road, on the road and off shore adventure. Perfect for boats, campervans, motorhomes , caravans, mountain top cabins, sandy shored beach huts, long distance lorry drivers, even the shed at the end of your garden.

The stainless-steel water tanks are all fully insulated, water is heated to 65°-70° in round an hour.

We recommend you install a thermostatically controlled mixer tap to dispense your water at a safe 40°- 45°C allowing even a modest tank of warmed water to go a long way. Water can be heating up whilst your underway and with the benefits of solar or wind charging of your 12v battery warm water can keep on flowing.

The Pundmann range of campervan water heaters are built so that you can stay wild, in off grid creature comfort.

Uniquely Compact

Smaller than a box of beer, the new EPP soft shell still
provides all the benefits of the EPS shell.

EPP – expanded polypropylene foam is a high-performance
superior insulation with exceptionally high strength to weight ratio and
superior chemical, oil and heat resistance and has provided our installers so
many benefits when fitting into tight spots.

Caption

Easy to Install

We have modified the design of the stainless steel spigots
to more easily enable our installers to convert their installation between 10mm
internal diameter with hose clips to push fit connectors.

The 22mm extended smooth wall sits behind the barbed section
that can be removed with a high quality pipe cutter or hacksaw.

Integration with SavvyVan

SavvyVan are gaining traction fast as a leading interface
control pannel for campervans across Europe. Pundmann syncs automatically with
SavvyVan to give you full control at your fingertips. Alternatively feel free
to use your own system to control the water heater.

Nation Wide Installers

Pundmann water heaters are used by campervan installers across the UK.

CLICK HERE for the installer map

FAQs

How is the water heated?

3 ways depending on the heater

  • 12v – Has a 180w (3L) or 200w (6L& 9L) immersion heater
  • 230v (240v compatible) has a 500w immersion heater

Air Model – uses the hot air flow from a diesel heater, efficiently through the cylinder heat exchanger

How much power does it take?

DC 12V     180W = 15.00 A
DC 12V     200W = 16.67 A

AC 24V     200W =   8.33 A



AC 240V    200W =   1.04 A

AC 240V    500W =   2.08 A

Which size tank do I need?

3 or 6 litre – Consider the availability of cold water and the space you have available

A modest shower uses around 5litres of water so our 6L model would provide more than enough water for a couple of showers

A 3L unit will provide adequate hot water for washing up and a quick wash down.

What are the dimensions?

3l – (WxDxH): 228 x 217 x 200 mm

6l – (WxDxH): 228 x 360 x 200 mm

9l – (WxDxH): 228 x 520 x 220 mm

The units require approximately 85mm allowance to the depth for the pipes and pressure release valve

For more information on the products see our Installation and user guides page in the footer of our website
